Below is a guide on how to import SCHURKEE 3D scans and general datasets into CAD environments and how to get started, working with scans as your design reference.
Sourcing a high accuracy 3D scan can be difficult in itself. Scan datasets are typically niche as is, but this becomes even more difficult with older vehicle models due to the added rarity and lack of continued aftermarket support as they are often forgotten.
However, once you have managed to source one, be it for an RX-7 FC3S, Z20 Soarer or Daihatsu Copen L880K, the next question we get is always the same:
How do I actually work with this in a CAD environment?
This guide has been put together to walk through the essential workflow, from importing a 3D scan STL and using it as an accurate design reference for anything from reverse engineering through to producing your own custom aero and bodykit designs for your projects or company.
First things first - to be able to understand the fundamentals, we have to start at square one. An STL file represents a 3D shape using thousands, or millions, of tiny triangles which together form a mesh. In the case of 3D scanning, this mesh is created using the data captured from the physical object. However, STL files aren't exclusive to 3D scanning, they're more commonly used for 3D printing (which you may recognise the format from most) as well as exporting mesh geometry from other 3D software.
Unlike traditional CAD geometry, an STL contains only triangulated mesh geometry. STLs have no feature tree or parametric history and instead represent the shape entirely through the mesh itself, which is both good and bad. It is good as it provides a good record of the real-world captured geometry from the scanner, but bad as it cannot be edited as easily - unlike a native CAD body.
At SCHURKEE, our 3D scans are captured at sub-millimetre accuracy, depending on the scan - this gives us a reliable reference for panel gaps, curvature transitions and mounting geometry.
Most professional CAD and surfacing tools can import STL directly:
The most common workflow is to use the scan as a foundation, a locked reference body, while you build new parametric geometry on top of it. You can then:
We strongly recommend you check out Making for Motorsport's tutorial on reverse-engineering, specifically for working with 3D scans, using Fusion360 which hobbyists can get a free licence.
At SCHURKEE, our personal favourite workflow is to process scan data, once aligned, through dedicated reverse-engineering software such as QUICKSURFACE or Geomagic Design X, as these packages allow usable surfaces and CAD geometry to be reconstructed directly from the scan.
Additionally, the resulting geometry can then be exported into your CAD software of choice, giving you a much clearer and stronger foundation for designing parts, whilst also retaining the original scan as a reference for checking fitment and surface accuracy.
Browse the SCHURKEE scan library for your platform:
